6
Rear view
Rear view
RISK OF E LECTRI C SHOCK
DO NOT OPEN
CAUTION
RISQUE DE CHOC ÉLECTRIQUE
NE PAS OUVRIR
ATTENTION
USB
AES
OPTICAL
COAX
IR
L
R
L
R
L
12
ANALOG < SOURCES > DIGITAL
1 ON: RCA Direct Out
2 ON: XLR Direct Out
5 ON: Ref +15dB
6 ON: Ref +18dB
3 ON: Zero flag auto-mute enabled
4 ON: RCA In -10dBV to 0dBuON BOTTOM SIDE:
DIP SWITCHES
Made in
Germany
OUT OUT R OUT L
R
B
A
Voltage Selection: 1. Remove Fuse Holder
2. Exchange Fuses 3. Flip Over 4. Reinstall
~115 V AC/~230 V AC, 50 Hz/60 Hz, P max. 45 W
Fuses: 230 V: T 500mA L 250V, 115 V: T 1 A L 250V
AMP CTL
IR
PGM
IR
PGM
SOURCE
VOLUME
Refer to
Manual
Digital Audio Inputs
7
Mains Switch
11
Mains Voltage
10
Analog Audio Inputs
8
Analog Audio Outputs
14
