VU meters
The VU meters () display the input levels for the selected source. The meter indicates levels from - dB to + dB.
 dB corresponds to + dBu.
If necessary you can lower the sensitivity by  dB so that the meters go up
to + dB intput level (see ”DIP switches“ on page).
The ballistics of the VU meters guarantee an optimal visual perception. The
time calibration of the VU meters complies with the requirements of the
BBC. The rise time up to  dB is about  ms.
