SPL Phonitor x - IR Remote Control

25
IR Remote control
The volume potentiometer can be remotely controlled using any infrared (IR) remote control.
The special feature is that the Phonitorx learns your remote and not the other way around. You do not need a learn-
able remote control. Take, for example, the remote control of the CD player. Out of the many buttons there are two
you hardly use if at all. Assign Volume up / Volume down to these two buttons and let the Phonitorx learn them.
• While learning the IR remote control commands set the OUTPUT switch () to Mute.
VUmeters light up red.
• Press the PGM IR VOLUME button () on the rear of the unit. The Power LED now lights up
brighter.
• Point your remote control towards the VU meters () and push the button you wish to use to
lower the volume. The power LED lights up once per push. Press the same button repeatedly
until the power LED lights up three times within a short interval – programming this button is
then completed.
• Point your remote control towards the VU meters () and push the button you wish to use to increase the
volume. The power LED lights up once per push. Press the same button repeatedly until the power LED
lights up three times within a short interval – programming this button is then completed.
(Learn mode ends automatically after the second button is learned.)
Mute
OUTPUT
Phonitor x
Serial
Number
Made in Germany
~ 115V AC / ~230V AC, 50 Hz / 60 Hz, P max. 45 W
R
B
A
PGM
VOLUME
Refer to
Manual
Connect to SPL
Power Amp(s) for
remote power on/off
AVIS: RISQUE DE CHOC ÉLECTRIQUE • NE PAS OUVRIR
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
Fuses:
Voltage Selection:
230V AC: T 500 mA L 250 V
115V AC: T 1 A L 250 V
1. Remove Fuse Holder
2. Exchange Fuses
3. Flip Over 4. Reinstall
XLRs: balanced, Pin 2 = Hot (+)
For unbalanced operation
bridge Pin 3 to GND.
RCAs: Unbalanced, Tip = Hot (+)
WIRING
ON BOTTOM SIDE:
DIP SWITCHES
1 ON: HP Out +22dB
2 ON: HP Out +12dB
3 ON: VU 0 = +10dB
4 ON:
XLR Direct Out
5 ON: RCA Direct Out
6 ON: AMP CTL power off
when listening to
SPEAKER OUTPUTS
RLRL
ANALOG SOURCES DIGITAL SOURCES
AMP CTL SPEAKER OUTPUTS
L
R
ANALOG SOURCES DIGITAL SOURCES
LR
USBOPTICAL
AMP CTL
R
L
R
L
LL
R
COAX
IR
I
F
R
B
