7
◇Interface: parallel interface (compatible with CENTRONICS) or serial
interface (compatible with RS-232C or TTL).
◇Interface connector: parallel port: 26-pin flat cable socket (T is DB25 orifice); serial
port: 10-pin flat cable socket or 5-pin single-row socket（T is DB25 needle）;
◇ Control code: ESC、FS control codes
◇ Reliability：MCBF （Average lines of none error）Reliability: MCBF:（5～15）× 10
6
◇ Power：DC5V±5% , 1.5A
◇ Operation temp：0～50℃,relative temp：10～80%
◇ Installation dimension details see the chapter 2
The Main Characteristics of SP Series Printers
Model Character/line
（5×7）
Character
dimension(mm)
Dots/line
Speed（line/s）
16Series 16
1．8×2.5(W×H)
96 1.2
24 Series 24
1．7×2.4(W×H)
144 0.7
40Series 40
1．1×2.4(W×H)
240 0.4
24F Series 24
1．7×2.6(W×H)
144 2.5
40F Series 40
1．1×2.6(W×H)
240 1.5
