16
APV_SD4_ATEX_UK-0_122018.indd
UK
Double seal valve
DELTA SD4-ATEX
Instruction Manual: UK - rev. 0
APV
9.7. DELTASD4kvsvaluesinm³/h
SD41, SD42
SDE43, SDE44
SD41, SD42
SDE43, SDE44
DN
25 19 20
40 42 39
50 88 70
65 145 120
80 175 190
100 220 265
Inch
1" 15 16
1,5" 39 26
2" 79 63
2,5" 124 106
3" 155 150
4" 215 258
9. TechnicalData
