SPX FLOW APV DELTA SD4 Series User Manual

1
APV_SD4_ATEX_UK-0_122018.indd
UK
Double seal valve
DELTA SD4-ATEX
Instruction Manual: UK - rev. 0
APV
Content Page
1 General Terms 2
1.1. Symbols
1.2. ResponsibilityforATEXcertication-Scopeofsupply
2. Safety Instructions 3 - 4
3. Identicationofvalves,Temperatureclasses,Responsibilites  5-6
3.1. IdenticationofvalvesforapplicationinATEXenvironment
3.2. Temperature classes and permissible temperatures
3.3. Responsibilities
4. IntendedUse  6
5. ModeofOperation  7
5.1. General terms
6. Cleaning        8
6.1. Cleaning recommendation
6.2. Leakage chamber
6.3. Cleaning recommendation - leakage chamber
6.4. Hosing of leakage valves
7. Installation  8-9
7.1. General terms
7.2. Welding instructions
8. Dimensions/Weights  10-11
9. TechnicalData       12-15
9.1. General data
9.2. Compressed air quality
9.3. Closing times
9.4. Valve stroke
9.5. Pneumatic air consumption
9.6. Product pressures
9.7. Kvs values
10. Maintenance        16-17
11. ServiceInstructions  18-19
12. ServiceInstructions-Leakagevalves    20
13. ServiceInstructions-Actuator  21-22
14. ReconstructionofActuator  23
15. AssemblyTool  24
16. TroubleShooting  25
17. SparePartsLists  26
 SparepartslistDNandInchdesign  RNATEX054.62 
ActuatorSW4  RN01.054.86
 LeakagevalvesSD4  RN01.054.67

SPX FLOW APV DELTA SD4 Series Specifications

General

Brand	SPX FLOW
Model	APV DELTA SD4 Series
Category	Control Unit
Language	English
