SPX 2065 - Page 19

Figure 6 - Style "B" and "C" Less Base Plate
CT100-065
B
Y
Z
X
D
6.54 Sm Bore
10.47 Lg Bore
3.45 Sm Bore
5.74 Lg Bore
4.500 Sm Bore
6.85 Lg Bore
1” (1/4 keyway) Sm Bore
1.25 (1/4 keyway) Lg Bore
.56 Dia
6.25 Sm Bore
9.50 Lg Bore
B D
Model
Inlet
inch
(mm)
Outlet
inch
Sm Bore
inch
Lg Bore
inch
Sm Bore
inch
Lg Bore
inch
X
inch
Y
inch
Z
inch
P2045
1.5
(40)
1.5
(40)
16.39
(416)
--
3.0
(76)
--
3.88
(98)
1.81
(45)
2.25
(57)
P2045
2.0
(50)
1.5
(40)
16.39
(416)
--
3.0
(76)
--
3.88
(98)
1.81
(45)
2.25
(57)
P2065LV
1.5
(40)
1.5
(40)
16.71
(224)
--
2.0
(50)
5.2
(132)
4.75
(120)
1.94
(49)
3.19
(81)
P2065LV
2.0
(50)
1.5
(40)
16.71
(224)
--
2.0
(50)
5.2
(132)
4.75
(120)
1.94
(49)
3.19
(81)
P2065LV
2.5
(65)
1.5
(40)
16.71
(224)
--
2.0
(50)
5.2
(132)
4.75
(120)
1.94
(49)
3.19
(81)
P2065
2.5
(65)
2.0
(50)
17.30
(439)
--
2.0
(50)
5.2
(132)
4.44
(112)
1.94
(49)
3.94
(100)
P2065HV
3.0
(75)
2.0
(50)
17.93
(455)
21.30
(541)
2.0
(50)
5.2
(132)
4.44
(112)
1.94
(49)
3.94
(100)
P2075
3.0
(75)
1.5
(40)
17.19
(436)
20.42
(581)
1.0
(25)
4.2
(106)
6.69
(176)
1.75
(44)
4.50
(114)
P2085LV
2.0
(50)
1.5
(40)
17.19
(436)
20.42
(581)
1.0
(25)
4.2
(106)
6.69
(176)
1.75
(44)
4.50
(114)
P2085
3.0
(75)
2.5
(65)
18.41
(467)
21.90
(556)
1.0
(25)
4.2
(106)
5.63
(143)
2.53
(64)
5.06
(128)
P2085
4.0
(100)
2.5
(65)
17.91
(454)
21.40
(543)
1.0
(25)
4.2
(106)
5.63
(143)
2.03
(51)
5.06
(128)
P2105
4.0
(100)
-- --
22.57
(573)
--
3.2
(81)
6.94
(176)
2.86
(72)
6.75
(171)
P2105
6.0
(150)
-- --
22.60
(574)
--
3.2
(81)
6.94
(176)
2.90
(73)
6.75
(171)
Waukesha Cherry-Burrell Introduction
10/2010 95-03009 Page 19
NOTE: Dimensions X,Y, and B apply to pumps with clamp connections.
