SPX 2065 - Page 67

Waukesha Cherry-Burrell Parts Lists
10/2010 95-03009 Page 67
Style “C” Small Bore Pedestal Mount Parts
Bearing Housing, 2045 1 68-6
Bearing Housing, 2065 1 68-7
Bearing Housing, 2075 - 2085 1 68-8
2
Shaft 1 62-528X
* 3 Rear Bearing
123-101
* 4 Front Bearing
123-100
* 5 Retaining Ring
143-139
6
Seal, Outer 2 23-90
7
Seal, Inner 2 23-89
* 9 O-Ring, Inner
4 N70031
11
1/2-13 x 2 HHCS 4 30-138X
13
1/4-20 x 3/8" SHSS 2 30-178
14
Grease Fitting 2
BD0092000
15
Stand 1 4-34
16
1/2-13 x 1" HHCS 2 30-78X
* 17 O-Ring, Outer
2 N70041
Seal Guard, 2045 1 70-32
Seal Guard, 2065 / 2085, Small Bore 1 70-33
20
Cover Coupling, L.H. 1 70-29
21
Cover Coupling, R.H. 1 70-30
22
Brace, Cover Coupling 1 2-251
23
1/4-20 x 1/2" HHCS 8 30-62
26
End Cap Housing, Small Bore 1 23-92
56 Frame Coupling Half .625W 1 11-37
143T-145T Frame Coupling Half .875" 5S 1 11-101
182T-184T Frame Coupling Half 1.125" 5S 1 11-102
213T-215T Frame Coupling Half 1.375" 6S 1 11-103
254T-256T Frame Coupling Half 1.625" 7S 1 11-41
56 Frame Coupling Sleeve 4J 1 11-29
143T-184T Frame Coupling Sleeve 5JE 1 11-30
213T-215T Frame Coupling Sleeve 6JE 1 11-31
254T-256T Frame Coupling Sleeve 7JE 1 11-32
56 Frame Coupling Half 1.0" 4J 1 11-95
143T-184T Frame Coupling Half 1.0" 5S 1 11-94
213T-215T Frame Coupling Half 1.0" 6S 1 11-96
254T-256T Frame Coupling Half 1.0" 7S 1 11-97
32
1/2-13 x 1-1/2" HHCS 4 30-103
33
1/2" Washer 6 43-31
34
1/2" Lockwasher 4 43-16
PL5030-CH17
NOTES:
*
Recommended Spare Parts
NOTES
ITEM
NO.
DESCRIPTION
QTY.
PER
PUMP
PART
NO.
29
1
18
27
28
