SPX 2065 - Page 69

Waukesha Cherry-Burrell Parts Lists
10/2010 95-03009 Page 69
Style “C” Large Bore Pedestal Mount Parts
Bearing Housing, 2065 1 68-9
Bearing Housing, 2075 - 2085 1 68-10
Bearing Housing, 2105 1 68-11
2 Shaft 1 126985+
* 3 Rear Bearing
123-98
* 4 Front Bearing
1 CD0036300
6 Seal, Outer 2 23-95
8 Seal, Inner 1 23-93
* 10 O-Ring, Buna N, Inner
2 N70033
11 1/2-13 x 3-1/4" HHCS 4 30-221X
13 1/4-20 x 3/8" SHSS 2 30-178
14 Grease Fitting 2 BD0092000
15 Stand 1 4-35
16 1/2-13 x 1-1/4" HHCS 4 30-36X
* 17 O-Ring, Buna N, Outer
2 N70045
Seal Guard, 2065 / 2085 1 70-33
Seal Guard, 2105 1 70-37
20 Cover Coupling, L.H. 1 70-35
21 Cover Coupling, R.H. 1 70-36
22 Brace, Cover Coupling 1 2-252
23 1/4-20 x 1/2" HHCS 8 30-62
26 End Cap Housing, Large Bore 1 23-97
213T-215T Frame Coupling Half 1.375" 6S 1 11-103
254T-256T Frame Coupling Half 1.625" 7S 1 11-41
284T-286T Frame Coupling Half 1.875" 7S 1 11-105
324T-326T Frame Coupling Half 2.125" 8S 1 11-106
364T-365T Frame Coupling Half 2.375" 8S 1 11-107
213T-215T Frame Coupling Sleeve 6JE 1 11-31
254T-286T Frame Coupling Sleeve 7JE 1 11-32
324T-326T Frame Coupling Sleeve 8JE 1 11-33
364T-365T Frame Coupling Sleeve 8H 1 11-108
213T-215T Coupling Half 1.250" 6S 1 11-98
254T-286T Coupling Half 1.250" 7S 1 11-99
324T-365T Coupling Half 1.250" 8S 1 11-100
32 1/2-13 x 1-1/2" HHCS 4 30-103X
33 1/2" Washer 4 43-31
34 1/2" Lockwasher 4 43-16
PL5030-CH18
NOTES:
*
Recommended Spare Parts
NOTES
29
1
18
27
28
ITEM
NO.
DESCRIPTION
QTY.
PER
PUMP
PART
NO.
