3.0 MAINTENANCE
 DRYERISAPRESSURECONTAININGDEVICE.
DEPRESSURIZEBEFORESERVICING.
3.1 Ambient air filter - Clean accumulated dust
and dirt from ambient air filter monthly or
more often if air flow across the condens-
er is impeded.
A. Removetoppanel.
B. Removeambientairlterbyslidingupwards.
C. Washwithsoapandwaterandallowtodrybeforere-
installing.
NOTE:Donotusesolventstocleanambientairlter.
D. Reinstalllterandtoppanel.
3.2 Inlet strainer - clean inlet strainer monthly
or more often if rapid clogging occurs.
A. Shut-offcompressedairsupplytothestrainer 
 anddepressurize.
B. Removescreenandcleanorreplace.
C. Reinstall.
Screen
3.3 Replace separator/filter element yearly
or more often if pressure drop across the
dryer is excessive.
A. Shut-offcompressedairsupplytothedryerand 
 depressurize.
B. Removetoppanel.
C. Removetwoscrewsholdingsidepanelandremove 
side panel by sliding upwards.
D. Disconnectdraintubefrombulkheadtting
incabinetbase.Toremove,presstheplastic
collarin,towardthetting,whilepullingthetubeout
ofthetting.
E. Removebowl-pushbowlup,turnbowl1/8thturnto
yourleft,andpullstraightdown.
F. Cleanlterbowl.  
G. Replaceelement.
1. Replacingcompleteelement
 a) Pulloffoldelementanddiscard.
 b) MakecertainO-ringinsidetopof
replacement element is in place and push
  elementontolterhead.
2. Replacingsleeveonly
 a) Pullelementstraightdowntoremove.
 b) Removeboltandbottomcapandremove 
  disposableltersleeve.
 c) Cleanseparatorcorewithsoapandwater
  ifnecessary
 d) Slidenewltersleeveoverseparatorcoreand 
replace bottom cap and hand tighten bolt.
 e) MakecertainO-ringinsidetopofelementisin 
  placeandpushelementontolterhead.
