Technical Manual 2006
21
SRAM P5
TECHNICAL DATA / ASSEMBLY REQUIREMENTS
i-BRAKE for SRAM P5:
see page 54.
Version SRAM P5 Cargo:
see page 29.
Caution:
• SRAM P5 hubs are not suitable for
tandems, trademen’s delivery bicycles
and similar.
• SRAM P5 with coaster brake resp.
i-BRAKE are „DIN Plus City“ certified.
Cycle frame:
• Dropouts must be parallel.
• Slot width at rear dropout max. 10,5 mm.
• The strength must be such that with a
maximum braking torque of 250 Nm
(2200 in.lbs.) on the rear wheel no
residual deformation can occur on the
rear structure.
H
U
B
S
SRAM P5 with coaster brake SRAM P5 für i-BRAKE SRAM P5 with drum brake SRAM P5 without brake
Type MH 5215 — MH 5225 MH 5205
Brake Coaster i-BRAKE (see page 54) Drum „D“
❘
„NL“ None
Over Locknut Dim., OLD
122mm 126 mm 126 mm 122mm
Length, L 175 mm 179mm 179mm 175 mm
Ends Diameter, T FG 10.5
❘
FG 10.5 toothed cone
FG 10.5 FG 10.5 FG 10.5
Dropout Width Dim.
A
1
max.=12.5mm / A
2
max.=11.5mm A
1
max.=12.5mm / A
2
max.=12.5mm A
1
max.=12.5mm / A
2
max.=10.5mm A
1
max.=12.5mm / A
2
max.=10.5mm
Holes 36 36 36 36
Hole Diameter, DS 3,0mm 3,0mm 2,9mm 3,0mm
Hole Ref. ø, HR 75 mm 75mm 89mm 75mm
Flange Dist. to
1
/
2
OLD
F
1
= 28.5mm / F
2
= 29.5mm F
1
= 31mm / F
2
= 27.7mm F
1
= 30.5mm / F
2
= 29.5mm F
1
= 29mm / F
2
= 29mm
Totally 251%
Speed 1
63
%
Speed 2
78
%
Speed 3
100
%
Speed 4
128
%
Speed 5 1
58
%
Usable Dimensions
1
/
2
"x
1
/
8
" or
1
/
2
"x
3
/
32
"
1
/
2
"x
1
/
8
" or
1
/
2
"x
3
/
32
"
1
/
2
"x
1
/
8
" or
1
/
2
"x
3
/
32
"
1
/
2
"x
1
/
8
" or
1
/
2
"x
3
/
32
"
Line, C/D/E 49 /45.5/ 43mm 51.5/ 48.5/45.5 mm 51.5/48.5 /45.5mm 49 /45.5/ 43mm
Ratio 24", 26",28"= 1.8– 1.9 / 20"= 1.8– 2.0
Shifter SRAM Grip 5
Clickbox Clickbox P5
Hand Brake Lever — see page 55 see page 23 —
Tandem ———
Weight 1495g 1920g (complete with i-BRAKE) 1536g 1330g
Hub Shell Material
Steel Steel Aluminum Steel
Finish Matt Chrome Plated Matt Chrome Plated Clear Coat
❘
Clear o. Black
Matt Chrome Plated
➔ ➔ ➔
➔ ➔ ➔
➔ ➔
➔ ➔ ➔
➔ ➔ ➔
➔ ➔ ➔
➔ ➔ ➔
➔ ➔ ➔
➔ ➔ ➔
AxleSpokeGear Hub RatioChainCompatibilityFinish
T
L
OLD
1/2 OLD
A
2
max.
F
2
F
1
E
D
C
A
1
max.
7
min. 13.5
R 100
Ø 7.3
HR
DS
Version with coaster brake
3.5
NEW
NEW
NEW
NEW
NEW
NEW
