29
SRAM P5 CARGO
TECHNICAL DATA / ASSEMBLY REQUIREMENTS
Technical Manual 2006
Caution:
• The SRAM P5 Cargo is suitable for
tandems, trademen’s delivery bicycles
and similar. An additional external rear
brake is necessary due to the high load.
• SRAM P5 Cargo with coaster brake is
„DIN Plus City“ certified.
Tolerable stress:
Axle load: max. 120 kilograms
Torque/driver body: max. 85 Nm (750 in.lbs.),
no continuous stress.
Identification SRAM P5 Cargo:
Yellow grub screw inside the axle end.
Version SRAM P5 for normal bikes:
see page 21.
H
U
B
S
SRAM P5 Cargo with coaster brake SRAM P5 with drum brake
Typ MH 5215 Cargo MH 5225 Cargo
Brake Coaster Drum Version „D“
Over Locknut Dim., OLD
122mm 126mm
Length, L 175 mm 179mm
Ends Diameter, T FG 10.5
toothed cone
FG 10.5
Dropout Width Dim.
A
1
max. = 12.5mm / A
2
max. = 11.5mm A
1
max. = 12.5mm / A
2
max. = 12.5mm
Holes 36 36
Hole Diameter, DS 3.0mm 2.9mm
Hole Ref. ø, HR 75 mm 89mm
Flange Dist. to
1
/
2
OLD
F
1
= 28.5mm / F
2
= 29.5mm F
1
= 30.5mm / F
2
= 29.5mm
Totally 224%
Speed 1
67
%
Speed 2
78
%
Speed 3
100
%
Speed 4
128
%
Speed 5
150
%
Usable Dimensions
1
/
2
"x
1
/
8
" or
1
/
2
"x
3
/
32
"
1
/
2
"x
1
/
8
" or
1
/
2
"x
3
/
32
"
Line, C/D/E 49 /45.5/ 43mm 51.5/ 48.5/45.5 mm
Ratio 24", 26",28"= 1.8– 1.9 / 20"= 1.8– 2.0
Shifter SRAM Grip 5
Clickbox Clickbox P5
Hand Brake Lever — see page 31
Tandem Yes Yes
Weight 1495g 1536g
Hub Shell Material
Steel Aluminum
Finish Matt Chrome Plated Clear Coat
➔
➔
➔
➔
➔
➔
➔
➔
➔
AxleSpokeGear Hub RatioChainFinish Compatibility
CARGO
CARGO
Cycle frame:
• Dropouts must be parallel.
• Slot width at rear dropout max. 10,5 mm.
• The strength must be such that with a maximum braking torque of 250 Nm (2200 in.lbs.) on the rear wheel no
residual deformation can occur on the rear structure.
T
L
OLD
1/2 OLD
A
2
max.
F
2
F
1
E
D
C
A
1
max.
7
min. 13.5
R 100
Ø 7.3
HR
DS
Version with coaster brake
3.5
NEW
NEW
NEW
NEW
NEW
NEW
