19
Caliper Brake Hose Installation
Insert the compression fitting and hose into the caliper. Insert the compression fitting and hose into the caliper.
Tighten the compression nut.Tighten the compression nut.
Install the rubber boot onto the compression nut.Install the rubber boot onto the compression nut.
Spray isopropyl alcohol on the caliper and clean it with a shop towel.Spray isopropyl alcohol on the caliper and clean it with a shop towel.
⚠ CAUTION
Servicing your brakes removes all of the fluid from the system. You must bleed the brakes after you service the brake caliper and/or lever.
For brake bleed and brake hose shortening instructions, visit www.sram.com/service.
6
8 mm flare nut wrench 8 N·m (71 in-lb)
7
8
