SRAM G2 R User Manual

32
Reservoir Cap Installation
Reservoir Cap Installation
Press the bladder into the reservoir cap, make sure the bladder is Press the bladder into the reservoir cap, make sure the bladder is
properly seated into the reservoir cap. The bladder should be flush properly seated into the reservoir cap. The bladder should be flush
with the cap.with the cap.
Insert the reservoir cap/bladder assembly onto the lever body.Insert the reservoir cap/bladder assembly onto the lever body.
Use a torque wrench and a T10 TORX bit socket to tighten each Use a torque wrench and a T10 TORX bit socket to tighten each
reservoir cap bolt to 1.2 N·m (10.5 in-lb).reservoir cap bolt to 1.2 N·m (10.5 in-lb).
1
2
3
T10 1.2 N•m (10.5 in-lb)
