SRAM G2 R User Manual

31
R Lever Blade Installation
Line up the cam and lever blade with the holes in the lever body, then Line up the cam and lever blade with the holes in the lever body, then
press the pivot pin through the holes.press the pivot pin through the holes.
Use a hammer to gently tap the pivot pin into the pivot hole.Use a hammer to gently tap the pivot pin into the pivot hole.
Make sure the lever return spring is seated properly in the lever. The Make sure the lever return spring is seated properly in the lever. The
outboard end of the spring must press against the lever blade, while outboard end of the spring must press against the lever blade, while
the inboard end of the spring must press against the lever body. If the the inboard end of the spring must press against the lever body. If the
return spring is not seated properly, you will not be able to adjust the return spring is not seated properly, you will not be able to adjust the
reach of the lever blade.reach of the lever blade.
3
Hammer
