SRAM Guide T Caliper User Manual

10Caliper Piston Removal
Caliper Piston Removal
NOTICE
DOT fluid will damage painted surfaces. If any fluid comes in contact with a painted surface (e.g your frame) or printing on the brakes, wipe it off
immediately and clean it with isopropyl alcohol or water. Damage to painted and/or printed surfaces by DOT fluid is not covered under warranty.
Install the pad retention bolt.
Insert the Guide™ pad spacer so that it snaps onto the pad retention
bolt.
Squeeze the brake lever numerous times to advance the pistons until
they contact the pad spacer.
Remove the banjo bolt.
Remove the pad spacer.
Remove the pad retention bolt.
1
2.5 mm 20 mm or 15 mm Thru Axle
2
3
T25 Rubber-tipped blow gun chuck nozzle 22 mm
4
2.5 mm QR
