SRAM Guide T Caliper User Manual

9Caliper Brake Pad Removal
Caliper Brake Pad Removal
Use a 5 mm hex wrench to remove the brake caliper from the fork or
frame.
Remove the caliper mounting bracket and hardware from the caliper
then set them aside in the order that they were removed.
Remove the E-clip from the pad retention bolt.
Remove the pad retention bolt from the caliper.
Remove the brake pads and pad H-spring from the caliper.
NOTICE
If the brake pad thickness is less than 3 mm, replace the pads.
1
2
Needle nose pliers 20 mm or 15 mm Thru Axle
2.5 mm QR
3
Digital Caliper
2.7-3.2 N•m (24-28 in-lb) 22 mm
