Lower Leg Seal Service
Remove the outer wire spring from each new wiper seal and set them Remove the outer wire spring from each new wiper seal and set them
aside. aside.
Insert the narrow end of a new wiper seal into the recessed end of the Insert the narrow end of a new wiper seal into the recessed end of the
30 mm RockShox Dust Seal Installation tool.30 mm RockShox Dust Seal Installation tool.
Hold the lower leg steady and use a mallet to seat the dust wiper seal Hold the lower leg steady and use a mallet to seat the dust wiper seal
into the lower leg until the seal surface is flush with the top of the lower into the lower leg until the seal surface is flush with the top of the lower
leg.leg.
Repeat on the other side.Repeat on the other side.
NOTICE
Only press the wiper seal into the lower leg until it is flush with the
top surface of the lower leg. Pressing the wiper seal below the top
surface of the lower leg will compress the foam rings.
Install the outer wire spring.Install the outer wire spring.
200 Hour Service Continue the 200 Hour Service with Air Spring Service.
