9
Exploded View - RUDY
Exploded View - RUDY
Top cap
Top cap cover (Base)
Air shaft
Bottom out platform
Bottom bolt
Air piston
Retaining ring
Rebound adjuster
Rebound
bottom nut
Maxle insert
Rebound damper shaft
Compression damper
Rebound adjuster
mechanism
Rebound adjuster
adapter
Top cap
Volume Reducer
Lockout adjuster knob
(Ultimate)
Lower leg
Seal head
Bottom out bumper
Air shaft stud
Maxle insert
Split keeper and o-ring
Wiper seal
Air Spring Assembly
Compression Damper
Assembly
Rebound Damper
Assembly
Air valve cap
Rebound
housing
bolt
