SRAM ROCKSHOX RUDY XPLR User Manual

30
Charger Race Day Damper Installation
200 Hour Service Charger Race Day Damper Installation
Install the Charger Race Day Damper into the damper side upper tube. Install the Charger Race Day Damper into the damper side upper tube.
Install the top cap and tighten. Install the top cap and tighten.
UltimateUltimate: Install the adjuster knob with the tab in the 11 o'clock, : Install the adjuster knob with the tab in the 11 o'clock,
unlocked position, then tighten the retaining screw. Check the adjuster unlocked position, then tighten the retaining screw. Check the adjuster
knob to verify it rotates into the "Locked" position.knob to verify it rotates into the "Locked" position.
BaseBase: Thread on the damper cap.: Thread on the damper cap.
200 Hour Service 200 Hour Service Continue the 200 Hour Service with Continue the 200 Hour Service with Lower Leg InstallationLower Leg Installation..
1
2
Top Cap/Cassette Tool 28 N·m (250 in-lb)
3
Ultimate 2 mm 0.4 N·m (3 in-lb)
Base
