Lower Leg Removal and Service
Lower Leg Removal and Service
50/200 Hour Service Lower Leg Removal
Ultimate:Ultimate: Make sure the compression is unlocked. Make sure the compression is unlocked.
Remove the air valve cap. Remove the air valve cap.
Depress the Schrader valve and release all air pressure.Depress the Schrader valve and release all air pressure.
⚠ CAUTION  EYE HAZARD
Verify all pressure is removed from the fork before proceeding.
Failure to do so can result in injury and/or damage to the fork. Wear
safety glasses.
NOTICE
The Maxle inserts are reverse threaded. To avoid damaging the fork when removing or installing Maxle inserts, carefully read the instructions and
follow directional arrows.
Use an 8 mm hex wrench to remove the Maxle insert from the spring Use an 8 mm hex wrench to remove the Maxle insert from the spring
side of the lower leg by rotating the insert side of the lower leg by rotating the insert clockwiseclockwise. .
1
Ultimate
2
Small Hex
3
8 mm 8 mm
4
