11
Lower Leg Removal
Use an 11 mm hex wrench to remove the Maxle insert from the damper Use an 11 mm hex wrench to remove the Maxle insert from the damper
side of the lower leg by rotating the insert side of the lower leg by rotating the insert clockwiseclockwise. .
Remove the rebound housing boltRemove the rebound housing bolt from the damper side of the lower from the damper side of the lower
leg.leg.
Holding the fork horizontally to remove the rebound set screw will Holding the fork horizontally to remove the rebound set screw will
assist in removing the rebound assembly from the lower leg. assist in removing the rebound assembly from the lower leg.
Remove the rebound mechanism from the damper side of the lower Remove the rebound mechanism from the damper side of the lower
leg. leg.
Remove the black rebound adjuster adapter from the rebound bottom Remove the black rebound adjuster adapter from the rebound bottom
nut. Check that the o-ring is around the rebound nut. If not, it may be nut. Check that the o-ring is around the rebound nut. If not, it may be
resting on the bottom bolt; use a pick to remove it from the lower leg resting on the bottom bolt; use a pick to remove it from the lower leg
and install it on the rebound nut. and install it on the rebound nut.
11 mm 11 mm
5
6
T10
7
2.5 mm Rebound adjuster adapter
2.5 mm
