SRAM ROCKSHOX RUDY XPLR User Manual

24
Charger Race Day Damper Service
Charger Race Day Damper Service
200 Hour Service Charger Race Day Damper Removal
Ultimate:Ultimate: Loosen the set screw inside the lockout knob, and remove Loosen the set screw inside the lockout knob, and remove
the lockout adjuster knob.the lockout adjuster knob.
Base:Base: Remove the damper cap. Remove the damper cap.
Remove the Race Day Damper assembly.Remove the Race Day Damper assembly.
Clean the upper tube threads.Clean the upper tube threads.
Replace the o-ring on the top cap. Replace the o-ring on the top cap.
1
2 mm Ultimate Base
2
Top Cap/Cassette Tool
3
