33
Lower Leg Installation
Install the silver bottom bolt into the Install the silver bottom bolt into the spring side spring side shaft of the lower leg. shaft of the lower leg.
Install the rebound bottom nut into the Install the rebound bottom nut into the damper sidedamper side shaft of the lower shaft of the lower
leg. Be careful not to push the damper shaft back through the bolt hole.leg. Be careful not to push the damper shaft back through the bolt hole.
Install the rebound mechanism into the damper side lower leg, making Install the rebound mechanism into the damper side lower leg, making
sure to fully seat the rebound adjuster adapter into the bottom nut. sure to fully seat the rebound adjuster adapter into the bottom nut.
Use a 2.5 mm hex wrench or the Rebound Adjuster to hold the Use a 2.5 mm hex wrench or the Rebound Adjuster to hold the
rebound mechanism against the lower leg, align the bolt holes, and rebound mechanism against the lower leg, align the bolt holes, and
install the rebound housing bolt.install the rebound housing bolt.
Refer to your pre-service recorded rebound setting to adjust the Refer to your pre-service recorded rebound setting to adjust the
rebound. rebound.
5 mm (minimum
110 mm length)
Spring Side
5 mm (minimum
110 mm length)
6.8 N·m (60 in-lb)
7
5 mm (minimum
110 mm length)
Damper Side
5 mm (minimum 110 mm length) 6.8 N·m (60 in-lb)
8
2.5 mm hex T10
