44
Lower Leg Installation
Install the lower leg assembly onto the upper tubes and slide it just
enough to engage the upper bushings with the upper tubes.
NOTICE
Make sure both wiper seals slide onto the tubes without folding the
outer lip of either seal.
The inside bottom of the lower leg should not contact the spring or
damper shafts. A gap between the shaft ends and the lower leg bolt
holes should be visible.
Position the fork at an angle with the bolt holes oriented upward.
Inject 6 mL of RockShox® 15wt suspension oil into each lower leg
through the bottom bolt holes.
NOTICE
Do not exceed the recommended oil volume per leg as this can
damage the fork.
4
5
