45
Lower Leg Installation
Slide the lower leg assembly toward the crown until it stops.
The spring and damper shafts should be visible through the bottom
bolt holes.
Verify each shaft is centered and seated in the lower leg shaft/bolt hole
and no gap is visible between the lower leg and the shaft end.
200 Hour Service Remove the old crush washer retainer and crush
washer from each bottom bolt.
Compress and hold the crush washer retainer with needle nose pliers
and unthread it, and the crush washer, from the bolt by turning the bolt
counter-clockwise.
Install a new crush washer retainer and crush washer onto each bolt.
NOTICE
Do not damage the bolt threads.
Do not reuse crush washers or crush washer retainers. Dirty or
damaged crush washers can cause oil to leak from the fork.
6
7
