SRAM RockShox SEKTOR User Manual

46
Lower Leg Installation
Install the solid bottom bolt into the spring side shaft.
Install the hollow bolt into the damper side shaft.
Tighten each bolt.
Apply a small amount of grease to the end of the rebound adjuster hex
and around the outside of the damper bottom bolt. Install the rebound
adjuster knob onto the rebound damper bottom bolt.
Press the knob firmly onto the bolt until it clicks into place.
Refer to your pre-service recorded rebound setting to adjust the
rebound damping.
8
5 mm Spring side
5 mm 6.8 N·m (60 in-lb)
5 mm Damper side
5 mm 6.8 N·m (60 in-lb)
9
