15
BINDING AND CLEAT
Adjust the spring force to the optimal
cleat holding force as needed when
releasing the cleats from the bindings.
The adjustment bolt is located at the
rear of each binding. To adjust the spring
tension use a 3mm allen key.
Clockwise rotation will increase and
counter clockwise will decrease the
holding force. Make sure to adjust both
bindings on each pedal equally.
Position the cleat (A) followed by the
cleat adapter (B) on to the sole of the
shoe and then temporarily tighten them
with the cleat mounting bolts (C) with a
4mm allen key. Make sure the arrow is
pointing toward the front of the shoe. The
cleats are compatible with both left and
right pedals. Tightening torque 5 - 6Nm
(3.7 - 4.4 ft-lbf).
A
B
C
