CHARGING THE PEDALS
To charge the X-Power pedals attach the
magnetic charge adapter to a USB wall charger
(not included) with the enclosed USB cable.
Connect the adapter onto the charge port on
the pedal shaft. A blinking red LED indicates
that the pedal is charging. Once the pedal is
fully charged the LED will blink green. A full
charge cycle takes approximately three hours.
I NOTE
When charging the pedals the internal
electronics goes in standby automatically. To
re-activate the pedal remove the charger and
turn the pedal.
A blinking yellow LED indicates cadence for the
rst couple pedal revolutions. If the cadence
LED is blinking red the pedal battery is low and
should be recharged!
I NOTE
Using crank boots on your crank can cover
the charge port and make charging impossible
when mounted. Add pedal spacers or remove
the boot if necessary.
USB Micro-B cable
Magnetic charge adapter
Charge port one side only
Status LED
