SERVICE AND MAINTENANCE
13-6
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
ENGINE OIL
Level Check
Park the vehicle on a level ground and apply the parking
brake. Stop the engine and wait more than 5 minutes.
1. Pull out the dipstick and wipe it with a clean cloth. Rein-
sert it all the way.
2. Pull out it again and check the oil level.
3. The oil level should be between the maximum (Max)
mark and minimum (Min) mark on the oil dipstick. Oil
should be replenished before the level goes below the
minimum mark.
Replenishment
1. If the level gets to the lower point, open the filler cap on
top of the cylinder block and add the genuine oil without
exceeding the level of the upper mark.
2. Recheck the oil level after 5 minutes.
Diesel Engine
Gasoline Engine
Min
Max
Engine oil
dipstick
Engine oil
filler cap
Min
Max
Engine oil
dipstick
Engine oil
filler cap
