INSTRUMENT CLUSTER
5-14
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
4WD INDICATORS (PART TIME T/C ONLY)
4WD Low Indicator
When shifting the driving mode to “4L”, this
indicator blinks until the shifting operation
is completed. After completion of the mode
change to 4L, the indicator comes on.
4WD Check Warning Light
This warning light comes on when the igni-
tion switch is turned to “ON” and should go
out if the system is normal. If the “4WD
CHECK” warning light stays on, have the
4WD system checked by a Ssangyong Dealer
or Ssangyong Authorized Service Center.
4WD High Indicator
When shifting the driving mode from “4L” to
“4H”, this indicator blinks until the shifting
operation is completed. After completion of
the mode change to 4H, the indicator comes
on. Shift the driving mode from 2WD to 4WD
HIGH only when the vehicle speed is under
70 km/h.
• If the “4WD CHECK” warning light stays on, have the 4WD sys-
tem checked.
• Do not drive your vehicle over 80 km/h in 4H mode.
CAUTION
When shifting the driving mode from 4WD LOW to 4WD HIGH, this
indicator will blink until the shift is completed. After completion of
the shifting operation, the indicator stays on. The indicator comes
on without blinking when shifting from 2WD to 4WD HIGH.
NOTE
