4–4 SEAT AND RESTRAINT
FRONT SEAT SLIDE
ADJUSTMENT (POWER SEAT)*
To move the seat forwards or backwards
electrically, slide the control lever forwards
or backwards.
Then, slide the seat electrically to the de-
sired position and release the control lever.
DRIVER’S SEAT HEIGHT
ADJUSTMENT (POWER SEAT)*
To adjust the driver’s seat height, move the
control lever upwards or downwards. Raise
or lower the seat electrically as required by
seating on the driver’s seat (applying load).
DRIVER’S SEAT TILT
ADJUSTMENT (POWER SEAT)*
To adjust the front and/or rear portion of the
cushion respectively, move the front and/or
rear of the control lever upwards or down-
wards separately.
1. Up : Front portion of the seat cushion
2. Down : Front portion of the seat cushion
3. Up : Rear portion of the seat cushion
4. Down : Rear portion of the seat cushion
