4–10 SEAT AND RESTRAINT
3. Pull up the lever from under the left and
right seat to release the lock and fold the
seat forward.
WARNING
•
After folding the seat back, press
the upper portion of the seat to
lock and then lift it up. When the
seat is lifted up without locking,
there could be interventions be-
tween rear console box cover
handle and seat to be damaged.
•
Before lifting up the seat, make
sure that the rear console box
cover is closed.
4. Completely contact the seat to the front
seats and take out the strap from the
bottom box and fasten the seat safely.
The strap should be hooked to the pole
of front seat head restraint.
UNFOLDING SECOND SEAT
(FROM REAR SIDE)
1. Unhook the strap and put into the bot-
tom box.
2. Lock the seat to the floor (make sure of
the locking-if not locked, the seat may
fall over during driving).
3. Unfold the seat back while pressing the
lever.
CAUTION
When unfolding the seat to its origi-
nal position, be careful not to cause
injuries on knees or feet to whom
seating on the third seat.
2
3
1
Push
to lock
