Hardware layout and configuration UM2408
44/51 UM2408 Rev 2
CN10
1 VDDA VDDA - Analog VDD -
3 AGND AGND - Analog ground -
5 GND GND - ground -
7 A6 ADC_A_IN PC1 ADC12_INP1 -
9 A7 ADC_B_IN PC5 ADC12_INP8 -
11 A8 ADC_C_IN PA2
(13)
ADC1_INP14 -
13 D26 QSPI_CS PG6 QSPI_BK1 -
15 D27 QSPI_CLK PB2
(4)
QSPI_CLK -
17 GND GND - ground -
19 D28 QSPI_BK1_IO3 PD13 QSPI_BK1 -
21 D29 QSPI_BK1_IO1 PD12 QSPI_BK1 -
23 D30 QSPI_BK1_IO0 PD11 QSPI_BK1 -
25 D31 QSPI_BK1_IO2 PE2
(7)
QSPI_BK1 -
27 GND GND - ground -
29 D32 TIMER_C_PWM1 PA0 TIM2_CH1 -
31 D33 TIMER_D_PWM1 PB0 TIM3_CH3 -
33 D34 TIMER_B_ETR PE0 TIM4_ETR -
2 D7 I/O PG12
(14)
- ARDUINO
®
support
4 D6 TIMER_A_PWM1 PA8
(15)
TIM1_CH1 ARDUINO
®
support
6 D5 TIMER_A_PWM2 PE11 TIM1_CH2
ARDUINO
®
support
8 D4 I/O PE14 -
ARDUINO
®
support
10 D3 TIMER_A_PWM3 PE13 TIM1_CH3
ARDUINO
®
support
12 D2 I/O PG14 -
ARDUINO
®
support
14 D1 USART_A_TX PB6 LPUART1
ARDUINO
®
support
16 D0 USART_A_RX PB7 LPUART1
ARDUINO
®
support
18 D42 TIMER_A_PWM1N PE8 TIM1_CH1N -
20 D41 TIMER_A_ETR PE7 TIM1_ETR -
22 GND GND - ground -
24 D40 TIMER_A_PWM2N PE10 TIM1_CH2N -
26 D39 TIMER_A_PWM3N PE12 TIM1_CH3N -
28 D38 I/O PE6
(8)
I/O -
30 D37 TIMER_A_BKIN1 PE15 TIM1_BKIN1 -
32 D36 TIMER_C_PWM2 PB10 TIM2_CH3 -
34 D35 TIMER_C_PWM3 PB11 TIM2_CH4
Table 18. NUCLEO-H7A3ZI-Q pin assignments (continued)
Connector Pin
Pin
name
Signal name
STM32H7
pin
Function Remark
