ST NUCLEO-H7A3ZI-Q User Manual

UM2408 Rev 2 41/51
UM2408 Hardware layout and configuration
50
For more details refer to Table 16: Solder bridges.
1. PC9 = SDMMC_D1 / SAI2_EXTCLK
2. PG10 = D49 / SMPS_SW
3. PG8 = D50 / SMPS_V1
4. PB2 = D27 / D72
5. PB5 = D11 (H745ZI / H755ZI) / D22 / D70
6. PB14 = D65 / LED_RED
7. PE2 = D31 / D56
8. PE6 = D59 / D38
9. PD10 = D64 / USB_FS_PWR_EN (H745ZI / H755ZI)
10. PB13 = D18 / RMII_TXD1 (H745ZI / H755ZI)
11. PB3 = D23 / SWO
12. PG9 = D8 / SMPS EN
13. PA2 = A8 / RMII_MDIO (H745ZI / H755ZI)
14. PG12 = D7 / SMPS_PG
15. PA8 = D6 / USB_SOF / MCO1
Table 18. NUCLEO-H7A3ZI-Q pin assignments
Connector Pin
Pin
name
Signal name
STM32H7
pin
Function Remark
CN8
1NC NC - -
ARDUINO
®
support
3 IOREF IOREF - 3.3 V Ref
ARDUINO
®
support
5 NRST NRST NRST RESET
ARDUINO
®
support
7 3V3 3V3 - 3.3 V input/output
ARDUINO
®
support
9 5V 5V - 5 V output
ARDUINO
®
support
11 GND GND - ground
ARDUINO
®
support
13 GND GND - ground
ARDUINO
®
support
15 VIN VIN - Power input
ARDUINO
®
support
2 D43 SDMMC_D0 PC8 SDMMC -
4D44
SDMMC_D1/
SAI2_EXTCLK
PC9
(1)
SDMMC/I2S_A -
6 D45 SDMMC_D2 PC10 SDMMC -
8 D46 SDMMC_D3 PC11 SDMMC -
10 D47 SDMMC_CK PC12 SDMMC -
12 D48 SDMMC_CMD PD2 SDMMC -
14 D49 I/O PG10
(2)
I/O -
16 D50 I/O PG8
(3)
I/O -
