Definition Bridge
Setting
(1)
Comment
OCTOSPI_CLK /
TIMER_C_PWM2
PB10
SB61
OFF PB10 is not used as OCTOSPI_CLK.
ON PB10 is used as OCTOSPI_CLK.
SB62
OFF PB10 is not used as a TIMER for motor control.
ON PB10 is used as a TIMER for motor control.
TIMER_C_PWM1 /
User-Button
PA0
SB60
OFF
PA0 is not used as a TIMER for motor control, reserved for the
user button.
ON
PA0 can be used as a TIMER for motor control, but cannot be
used as a user button.
OCTOSPI_IO3 /
TIMER_A_BKIN1
PE15
SB66
OFF PE15 is not used as OCTOSPI_IO3.
ON PE15 is used as OCTOSPI_IO3.
SB67
OFF PE15 is not used as a TIMER for motor control.
ON PE15 is used as a TIMER for motor control.
OCTOSPI_IO0 /
TIMER_A_PWM3N
PE12
SB68
OFF PE12 is not used as OCTOSPI_IO0.
ON PE12 is used as OCTOSPI_IO0.
SB69
OFF PE12 is not used as a TIMER for motor control.
ON PE12 is used as a TIMER for motor control.
OCTOSPI_IO2 /
TIMER_A_BKIN2
PE14
SB70
OFF PE14 is not used as OCTOSPI_IO2.
ON PE14 is used as OCTOSPI_IO2.
SB71
OFF PE14 is not used as a TIMER for motor control.
ON PE14 is used as a TIMER for motor control.
1. The default configuration is in bold.
Note: The OCTOSPI interface is used in quad
‑
mode communication without DQS to support Quad-SPI memories.
UM2861
Solder bridge configuration for the expansion connector
UM2861 - Rev 5
page 39/49
