STLINK-V3MODS and STLINK-V3MINI functional description UM2502
14/28 UM2502 Rev 2
Figure 8. MB1467 bottom layout
Figure 9. MB1467 mechanical drawing (in millimeters)
MSv61224V2
STDC14 connector
(CN5)
(STLINK-V3MINI only)
