STLINK-V3MODS recommended land pattern UM2502
22/28 UM2502 Rev 2
Appendix A STLINK-V3MODS recommended land pattern
Figure 11. STLINK-V3MODS recommended land pattern
MB1467
PCB edge of the host board
Do not place components
in this area
15.24 mm
29.97 mm
3 mm min.
