Hardware layout and configuration UM1724
42/55 DocID025833 Rev 4
Right connectors
CN5
digital
10 D15 PB8 I2C1_SCL
9 D14 PB9 I2C1_SDA
8 AREF - AVDD
7 GND - Ground
6 D13 PA5 SPI1_SCK
5 D12 PA6 SPI1_MISO
4 D11 PA7 TIM11_CH1 or SPI1_MOSI
3 D10 PB6 TIM4_CH1 or SPI1_CS
2 D9 PC7 TIM3_CH2
1D8 PA9 -
CN9
digital
8D7 PA8 -
7 D6 PB10 TIM2_CH3
6 D5 PB4 TIM3_CH1
5D4 PB5 -
4 D3 PB3 TIM2_CH2
3D2 PA10 -
2 D1 PA2 USART2_TX
1 D0 PA3 USART2_RX
1. Please refer to Table 9: Solder bridges for details.
Table 16. Arduino connectors on NUCLEO-L152RE (continued)
CN No. Pin No. Pin name MCU pin Function
To Next Page
