DocID025833 Rev 4 7/55

UM1724 Conventions

2 Conventions

Table 2 provides the conventions used for the ON and OFF settings in the present

document.

We refer to “STM32 Nucleo board” and “STM32 Nucleo boards” in this document for all

information that is common to all sale types.

Table 2. ON/OFF conventions

Convention Definition

Jumper JP1 ON Jumper fitted

Jumper JP1 OFF Jumper not fitted

Solder bridge SBx ON SBx connections closed by solder or 0 ohm resistor

Solder bridge SBx OFF SBx connections left open
