Connectors
UM2411
22/61
UM241
1 Rev 2
6 Connectors
6.1
USB OTG HS Micro-AB connector CN1
An USB OTG high speed communication link
is availa
ble at USB Micro-AB receptacle
connector CN1. Micro-AB receptacle e
nables USB Host and USB Device features.
Figure 8. USB OTG HS Micro-AB connector CN1
T
able 5. USB OTG HS Micro-AB connector CN1
Pin number
Description
Pin numbe
r
Description
1
VBUS
4
ID
2D
M
5
G
N
D
3D
P
-
-
06Y9
21
23
