UM2411 Rev 2 51/61
UM2411 STM32H747I-DISCO I/O assignment
60
Appendix A STM32H747I-DISCO I/O assignment
Table 21. STM32H747I-DISCO I/O assignment
Pin GPIO port GPIO primary interface
A1 VSS -
A10 PG9 QSPI_BK2_IO2
A11 PD5 PMOD#2- USART2_TX
A12 PD4 PMOD#4- USART2_RTS
A13 PC10 SDIO1_D2
A14 PA15 JTDI
A15 PI1 FMC_D25
A16 PI0 FMC_D24
A17 VSS -
A2 PI6 FMC_D28
A3 PI5 FMC_NBL3
A4 PI4 FMC_NBL2
A5 PB5 ULPI_D7
A6 VDDLDO -
A7 VCAP -
A8 PK5 JOY_RIGHT
A9 PG10 DCMI_D2
B1 VBAT -
B10 PJ15 Audio_INT
B11 PD6 PMOD#3- USART2_RX
B12 PD3 PMOD#18_DFSDM_CKOUT/DCMI_D5
B13 PC11 SDIO1_D3 || DCMI_D4
B14 PA14 JTCK-SWCLK
B15 PI2 FMC_D26
B16 PH15 FMC_D23
B17 PH14 FMC_D22
B2 VSS -
B3 PI7 FMC_D29
B4 PE1 FMC_NBL1
B5 PB6 HDMI_CEC
B6 VSS -
B7 PB4 NJTRST
