STM32H747I-DISCO I/O assignment UM2411
52/61 UM2411 Rev 2
B8 PK4 JOY_LEFT
B9 PG11 ETH_/TX_EN/TX_EN
C1 PC15-OSC32_OUT OSC32_OUT
C10 VSS -
C11 PD7 SPDIF_RX0
C12 PC12 SDIO1_CK
C13 VSS -
C14 PI3 FMC_D27
C15 PA13 JTMS-SWDIO
C16 VSS -
C17 VDDLDO -
C2 PC14-OSC32_IN OSC32_IN
C3 PE2 ETH_nINT || SAI4_CK1
C4 PE0 FMC_NBL0
C5 PB7 DCMI_VSYNC
C6 PB3 JTDO/TRACESWO
C7 PK6 JOY_UP
C8 PK3 JOY_DOWN
C9 PG12 ETH_/TXD1/TXD1
D1 PE5 SAI1_SCK_A
D10 PJ14 DCMI_PWR_EN
D11 PJ12 BL_CTRL
D12 PD2 SDIO1_CMD
D13 PD0 FMC_D2
D14 PA10 VCP-USART1_RX
D15 PA9 VCP-USART1_TX
D16 PH13 FMC_D21
D17 VCAP -
D2 PE4 SAI1_FS_A
D3 PE3 SAI1_SD_B
D4 PB9 PMOD#19_DFSDM-DATA7 || DCMI_D7
D5 PB8 PMOD#20_DFSDM-CK7 || DCMI_D6
D6 PG15 FMC_SDNCAS
D7 PK7 TOUCH_INT
D8 PG14 QSPI_BK2_IO3
Table 21. STM32H747I-DISCO I/O assignment (continued)
Pin GPIO port GPIO primary interface
