UM2411 Rev 2 53/61
UM2411 STM32H747I-DISCO I/O assignment
60
D9 PG13 ETH_/TXD0/TXD0
E1 VLXSMPS -
E10 PJ13 PMOD#12_GPIO
E11 VDD -
E12 PD1 FMC_D3
E13 PC8 SDIO1_D0
E14 PC9 SDIO1_D1 || DCMI_D3
E15 PA8 CEC_CK || MCO1
E16 PA12 PMOD#4-SPI2_SCK/2_CK
E17 PA11 PMOD#1-SPI2_NSS/2_WS
E2 PI9 FMC_D30
E3 PC13 TAMP_1/WKUP2
E4 PI8 uSD_Detect
E5 PE6 SAI1_SD_A
E6 VDD -
E7 PDR_ON -
E8 BOOT0 -
E9 VDD -
F1 VDDSMPS -
F13 PC7 PMOD#17_DFSDM_DATA3/DCMI_D1
F14 PC6 PMOD#11_INT/DCMI_D0
F15 PG8 FMC_SDCLK
F16 PG7 SAI1_MCLK_A
F17 VDD33USB -
F2 VSSSMPS -
F3 PI10 FMC_D31
F4 PI11 ULPI_DIR
F5 VDD -
G1 PF2 FMC_A2
G10 VSS -
G11 VSS -
G13 VDD -
G14 PG5 FMC_BA1
G15 PG6 QSPI_BK1_NCS
G16 VSS -
Table 21. STM32H747I-DISCO I/O assignment (continued)
Pin GPIO port GPIO primary interface
