2 Description of modes
The VD6383 device supports several modes that are described in the following diagrams. The diagrams in the
following sections show two channels, blue and red, enabled as an example to describe the device behavior.
2.1 Synchronous mode without intermeasurement period
The following diagram shows how to use the bare driver to collect light count values in synchronous mode without
any intermeasurement.
Figure 2. Bare driver signals without intermeasurement period
UM2878
Description of modes
UM2878 - Rev 1
page 3/27
