Installing Heat Sink Insert:
If the heat sink insert moves or shifts during seal removal, remove and replace
with a new insert to prevent leakage.
Removal:
1. Remove two screws holding heat sink insert to seal plate.
2. Place seal plate face down on bench and use a short length of 1/2”
(13 mm) pipe to push insert out of seal.
3. Remove O-Ring from insert cavity in seal plate and discard.
NOTICE: Do not scratch O-Ring seat in seal plate.
Installation:
1. Clean heat sink insert cavity in seal plate, including O-Ring seat (step in
seal plate cavity - Figure 7).
2. Lubricate new O-Ring with petroleum jelly and insert into seat in seal plate
(Figure 8).
NOTICE: O-Ring will roll out of position and leak of it is mounted on insert
before insert is installed. To prevent leaks around seal, install O-Ring in
seal plate cavity, not on heat sink insert. Push insert into seal plate cavity.
3. With thumbs near center if insert, line up screw slots in insert with screw
holes in seal plate; push insert into seal plate cavity (Figure 9).
4. Replace two screws in insert and tighten (Figure 10).
Figure 7: Clean O-Ring Seat.
Figure 8: Install O-Ring in Seal Plate
Figure 9: Line up screw holes and
press insert into place.
Figure 10: Tighten screws to secure
Insert to Seal Plate.
