STA-RITE MAX-E-GLAS II P4E6D-150L - Repair Parts List

13
P4E, P4EA and P4E62 SERIES
MAX-E-GLAS II POOL PUMP
3/4 and 3 HP Models
Motor No. Impeller Diffuser
Model No. HP (Key No. 1) (Key No. 13) (Key No. 14)
115/230 Volt
P4E6D-150L 3/4 AE100DHL C105-238P C1-271P1
P4E6E-151L 1 AE100EHL C105-238PB C1-271P1
P4EA6E-150L 1 AE100ELL C105-238P C1-271P1
P4EA6F-151L 1-1/2 AE100FLL C105-238PB C1-271P1
230 Volt
P4E6F-152L* 1-1/2 AE100FHL C105-238PDBA C1-271P
P4EAA6F-177L* 1-3/4 AE100F5LL C105-238PDCA C1-271P
P4E6G-153L* 2 AE100GHL C105-238PEBA C1-271P
P4EA6G-152L* 2 AE100GLL C105-238PDBA C1-271P
P4EAA6G-153L* 2-1/2 AE100G5LL C105-238PEBA C1-271P
P4E6H-154L* 3 AE100HLL C105-238PLA C1-271P
100/200 Volt
P4E62D-150L 3/4 AE100DH2 C105-238P C1-271P1
200 Volt
P4E62E-151L 1 AE100EH2 C105-238PB C1-271P1
P4E62F-152L* 1-1/2 AE100FH2 C105-238PDBA C1-271P
P4E62G-153L* 2 AE100GH2 C105-238PEBA C1-271P
P4E62H-154L* 3 AE100GHL2 C105-238PLA C1-271P
Parts are common to all models listed except as noted;
Key Nos. 1, Motor; and 13, Impeller are listed below.
Key Part Part
No. Description Qty. No.
1 Motor 1 Chart at Right
2 #10-32x1/2” Screw 1 U30-692SS
3 Bonding Lug 1 U17-568
4 Water Slinger 1 C69-2
5 Seal Plate 1 C203-187P
6 O-Ring 1 U9-376
7 O-Ring 1 U9-228A
8 Insert 1 C3-186
9 #8-32x1/4” Screw 2 U30-401SS
10 Shaft Seal 1 U109-372SS
11 Clamp 1 C19-37A
12 Clamp Knob 1 WC36-22
13 Impeller 1 Chart at Right
14 Diffuser 1 Chart at Right
15 Diffuser O-Ring 1 U9-374
16 #8 Lock Washer 5 U43-21SS
17 Screw (w/C1-271P Diffuser) 5 U30-922SS
17 Screw (w/C1-271P1 Diffuser) 5 U30-542SS
18 Tank Body 1 C176-59P
19 Basket 1 C8-58P
20 Trap O-Ring 1 U9-375
21 Trap Cover 1 C3-185P
22 1/4” NPT Drain Plug 2 U178-920P
23 Base w/Motor Pad** 1 C104-78P
24 Base Washer 2 U43-41SS
25 Base Screw*** 2 U30-918SS
26 Motor Pad 1 C35-43
27 3/8-16x1” Hex Hd. Screw 4 U30-74SS
• Voltage Sticker - 230 Volts† U27-68
• Voltage Sticker - 115/230 Volts†† U27-153
• Tag, “CAUTION, WARNING
(bonding)” 61002-0002
• Decal, “Do not overtighten...” U27-644
• Nameplate (P4E Series) 32155-4035
• Nameplate (P4EA Series) 32155-4071
REPAIR PARTS LIST
*Uses Impeller Screw No. 37337-6080
• Not illustrated.
** Models P4E6H and P4E62H use Base No. C104-79P and
Motor Pad No. C35-44.
*** Model P4E6F 1-1/2 HP uses Part No. U30-542SS.
† Single voltage models only.
†† Dual voltage models only.
