8
SP1: vertical beam emission aperture
SP2: rotation beam emission aperture
ON/OFF switch
Permanent adjustment On/Off selector switch
LEDs for displaying:
Red LED: battery voltage and overheat
Shock protection
5/8" threaded connector for tripod
Battery compartment cover
0049 / 63 46 / 3 09-0
GB
Main components
The STABILA LAR-200 rotation laser is an easy to operate rotation laser for horizontal
levelling and plumb lines in a sealed housing ( IP65). It is self-levelling in a range of
± 5°. The laser beam can be received at distances of up to 150 m with the use of a
receiver, even when it is no longer visible to the naked eye.
We have endeavoured to explain the unit's handling and functioning in as clear
and comprehensible manner as possible. If, however, you still have any unanswered
questions, we should be pleased to provide advice over the telephone at any time
on the following telephone number:
Operating instructions
Splitter pentaprism SP:
(4)
4 markings to create a plumb-line laser function
(1)
(3)
(2)
(5a)
(5b)
(6)
(7)
(8)
(9)
(10)
A
Housing: hoseproofed sealings and dustprotected acc. to standard IP65
Green LED: Operating mode ON or READY / OK
Recycling programme for our EU customers:
In accordance with the WEEE regulations, STABILA provides a disposal
programme for electronic products at the end of their service life.
For more details, please contact:
www.STABILA.de / Recycling
or:
0049 / 6346 / 309-0
Do not submerge the laser !
