LAX 50 G
5
en
Open the battery compartment cover in the direction of the
arrow and insert new batteries as indicated by the symbol
in the battery compartment.
Suitable rechargeable batteries can also be used.
Dispose of used batteries at suitable
collection points – not with household waste.
If you do not intend to use the unit for an
extended period, remove the batteries.
3 x 1.5 V
Alkaline
AA, LR6, Mignon
5.1 Inserting batteries/Battery replacement
5. Commissioning
The laser lines flash if the laser unit is at
too steep an angle.
The laser unit is outside the self-levelling
range and cannot level itself automatically.
Place the laser unit in the working position.
Use the sliding switch to switch on the laser unit.
Horizontal and vertical laser lines appear.
The LAX 50 G levels itself automatically.
Always use the centre of the laser line when marking and
aligning!
5.2 Switching the unit on

Stabila LAX 50 G Specifications

General

Wavelength	530 nm
Maximum range	30 m
Self-leveling	Yes
Number of laser lines	2
Leveling accuracy (±)	0.5 mm/m
Self-leveling range (±)	4.5 °
Operating time	7 h
Type	-
Certification	CE
Product color	Black, Yellow
Tripod thread	1/4, 5/8 \
Tripod mounting supported	No
International Protection (IP) code	IP53
