ASSEMBLY INSTRUCTIONS
STEP 3
Slide the UPRIGHT SLEEVE(72) over the UPRIGHT(4). Connect the EXTENSION CONTROL WIRE(63)
to the CONTROL WIRE(62). Insert the UPRIGHT(4) into the MAIN FRAME(1) and secure with HEX
HEAD BOLTS(M8x1.25x12mm)(49) and WASHERS(M8)(48). Slide down the UPRIGHT SLEEVE(72) to
cover the bolt heads.
